Descripción
Tabla de especificaciones
| Medida | Peso kg/m. |
Peso lbx/pie |
Patin Ancho mm. |
Patin Espesormm. |
Espesor del alma mm. |
|---|---|---|---|---|---|
|
6″ x 4″ 152.4 x 101.6 |
13.40 | 9.00 | 100.1 | 5.50 | 3.80 |
| 17.90 | 12.00 | 102.0 | 7.10 | 4.30 | |
| 23.80 | 16.00 | 102.0 | 10.30 | 6.60 | |
|
8″ x 4″ 203.2 x 101.6 |
14.90 | 10.00 | 100.0 | 5.20 | 4.30 |
| 19.40 | 13.00 | 102.0 | 6.50 | 5.80 | |
| 22.40 | 15.00 | 102.0 | 8.00 | 6.20 | |
|
8″ x 5 1/4″ 203.2 x 133.4 |
26.80 | 18.00 | 133.3 | 8.40 | 5.80 |
| 31.30 | 21.00 | 133.8 | 10.20 | 6.30 | |
|
10″ x 4″ 254.0 x 101.6 |
17.90 | 12.00 | 100.0 | 5.20 | 4.60 |
| 22.40 | 15.00 | 102.0 | 6.80 | 5.80 | |
| 25.50 | 17.00 | 102.0 | 8.40 | 6.10 | |
| 28.30 | 19.00 | 102.0 | 10.00 | 6.40 | |
|
10″ x 5 3/4″ 254.0 x 146.0 |
32.80 | 22.00 | 146.1 | 9.10 | 6.10 |
| 38.70 | 26.00 | 146.2 | 11.20 | 6.60 | |
| 44.70 | 30.00 | 147.2 | 12.90 | 7.60 | |
|
12″ x 4″ 304.8 x 101.6 |
20.90 | 14.00 | 100.0 | 5.70 | 5.10 |
| 23.80 | 16.00 | 101.3 | 6.70 | 5.60 | |
| 28.30 | 19.00 | 102.0 | 8.90 | 6.10 | |
| 32.80 | 22.00 | 102.0 | 10.80 | 6.60 | |
|
12″ x 6 1/2″ 304.8 x 165.10 |
38.70 | 26.00 | 164.8 | 9.70 | 5.80 |
| 44.70 | 30.00 | 165.6 | 11.20 | 6.60 | |
| 52.10 | 35.00 | 166.6 | 13.20 | 7.60 | |
|
12″ x 8″ 304.8 x 203.2 |
59.60 | 40.00 | 203.0 | 13.10 | 7.50 |
| 67.00 | 45.00 | 204.0 | 14.60 | 8.50 | |
| 74.40 | 50.00 | 205.0 | 16.30 | 9.40 | |
|
14″ x 6 3/4″ 355.6 x 171.4 |
44.70 | 30.00 | 171.0 | 9.70 | 6.90 |
| 50.60 | 34.00 | 171.0 | 11.50 | 7.30 | |
| 56.60 | 38.00 | 172.0 | 13.00 | 7.90 | |
|
14″ x 8″ 355.6 x 203.2 |
64.10 | 43.00 | 203.0 | 13.40 | 7.80 |
| 71.50 | 48.00 | 204.0 | 15.10 | 8.60 | |
| 79.00 | 53.00 | 205.0 | 16.70 | 9.40 | |
|
16″ x 7″ 406.4 x 177.8 |
53.60 | 36.00 | 177.0 | 10.90 | 7.60 |
| 59.60 | 40.00 | 178.0 | 12.70 | 7.80 | |
| 67.00 | 45.00 | 179.0 | 14.30 | 8.80 | |
| 74.40 | 50.00 | 180.0 | 15.90 | 9.60 | |
|
18″ x 7 1/2″ 457.2 x 190.5 |
74.41 | 50.00 | 190.4 | 14.48 | 9.02 |
| 81.85 | 55.00 | 191.3 | 16.00 | 9.91 | |
| 89.29 | 60.00 | 191.9 | 17.65 | 10.54 | |
| 96.70 | 65.00 | 192.8 | 19.50 | 11.40 | |
| 105.70 | 71.00 | 193.9 | 20.57 | 12.57 | |
|
18″x 11″ 457.2 x 279.4 |
113.10 | 76.00 | 280.3 | 17.30 | 10.80 |
| 128.00 | 86.00 | 281.7 | 19.60 | 12.20 | |
| 144.30 | 97.00 | 283.1 | 22.10 | 13.60 | |
| 157.70 | 106.00 | 284.5 | 23.90 | 14.90 | |
| 177.10 | 119.00 | 286.1 | 26.90 | 16.60 | |
|
24″ x 7″ 609.6 x 177.8 |
82.00 | 55.00 | 180.0 | 12.80 | 10.00 |
| 92.00 | 62.00 | 180.0 | 15.00 | 10.90 | |
|
24″ x 9″ 609.6 x 228.6 |
101.00 | 68.00 | 230.0 | 14.90 | 10.50 |
| 113.00 | 76.00 | 230.0 | 17.30 | 11.20 | |
| 125.00 | 84.00 | 230.0 | 19.60 | 11.90 |
